Flashjet Mini UV Printing Machine

PRODUCT PARAMETERS

• Print head : EPSON I3200
• Number of Print head : 1 Pc
• Nozzle spray force range : 2-3mm
• Number of nozzles : 3200 pcs
• Distance between nozzles : 1/300 inch
• Number of nozzle rows : 8
• Maximum number of supported ink colors : 8
• Effective print width : 300npi/1 row, 600npi/2 row, 1200npi/4 row
• Effective print width : 33.8mm
• Droplet ejection performance (droplet volume and ejection frequency) :
  2 levels of grayscale 5 pl (43.2kHz)
  3 levels of grayscale 6.12.5 pl (21.6kHz)
  4 levels of grayscale 3.8, 6.2, 9.3pl (21.6kHz)
• Rip Software : Future Rip
• Print speed : 0.28-3sqm/h
• Highest print resolution : 720 x 1200 dpi
• Print Size : 297 x 420 mm
• Print Version : White and color and varnish print at same time
• Print mode : CMYK+W+V/CMYKLcLm+W/CMYKLcLmLkLIk/CMYK
• Print height : 0-85 mm
• Printer dimension : 1000mm*902mm*592mm
• N.W. : 60KG
• Packing : 1.12m*1.02m*0.78m
• Size : 0.89cbm
• G.W. : 80KG
• Power : AC220/110V, 50HZ~60HZ
• Working environment : Temperature : 20 C-28 C Humidity : 35%-65%
• Connection method : Network cable
• Ink type : Environmental UV curing ink
• Ink store environment (shading) : Temperature : 20 C-28 C Humidity : 35%-65%
• Graphic format : Tiff, Jpg, Eps, Pdf, Png
• Launch : 2023
• Place of origin : Mainland China
• Packaging specification : Unit
• Machine color : Silver & White & Black
• Printer type : Digital inkjet printer
